Wood Construction - Looking better all the time!

Wood seems to be the obvious choice for the structural frame work in 1 & 2 family (residential) dwellings because of it's low cost, availability, and the familiarity of the work force with the skills required to work with wood.

So what about Commercial Construction? Many commercial structures are similar to residential, but I can think of three areas that change the most when comparing the needs for these buildings:

1. The Building Code – Although building codes for Residential construction are certainly more complex and complete in their reach than they have been, there aren’t as many trade offs in code requirements for various building materials as there are in the Commercial building codes. The advantage through the code development and lobbying process that goes with it is going towards materials other than wood as the code seems to limit commercial wood construction to smaller building sizes allowed and tighter sprinkler thresholds. Your own knowledge of the building code and easy access to a good Design Professional (ahem!) will allow you to better serve your building owners as you help them successfully navigate the choppy waters of today's building codes.

2. Average Sizes and Spans – the practical limits on span and size of wood structures continue to get pushed larger as we become smarter about how we use wood and combine it with other materials to achieve amazing things. I recently saw that a prominent wood connection manufacturer is currently testing a Seven (7!) story wood building in Japan for earthquake resistance. Also, realize that metal plate connected trusses are being used to clear span 60’, 80’, even 100’+ today by using dimensional lumber with Metal Plate Connectors. Compare these spans to what was possible with traditional rafters and ridge beams or rafters and collar ties that was the norm 2 generations ago and is still used in many residential buildings today. The irony is that the average size of available wood coming out of our forests is shrinking, but producers of engineered products are making stronger, straighter, and more reliable wood building materials out of these raw materials. This progress allows spans in wood construction today at the higher commercial floor and roof load requirements (of the building code, see #1) that would not be conceivable with the wood products available just a decade or two ago. Engineered use of Wood is making a difference!

3. Construction Budget – Typically higher for Commercial vs. Residential, however I think that this generalization has reversed its trend over the past 20 years as many new houses over the last decade have still been built much larger than needed (“McMansions”) while many businesses and multi-family developments are looking to build with the minimum capital requirement because the financial conditions reward the projects with the best cash flow, or return on investment. Advantage in the cost department: Wood!

There is another issue where wood has a clear advantage when comparing building materials and that is overall sustainability. The issue is quite simple but has been made complex in an by various political and special interest groups lately.

More about sustainability soon, but for now keep in mind, wood is good!

• Wood uses a very efficient and natural form of solar energy for its production (Photosynthesis!)... very little energy is required to harvest and process it
• Wood can be naturally grown and replaced faster than it's rate of consumption without sacrificing the environment in the process (now THAT'S sustainable!)
• Wood is easy to recycle or reuse or compost
• Wood buildings, when properly constructed, can last as long as any other material used in construction today.

Post Frame Building Definition

by Aaron Halberg, P.E.
Halberg Engineering LLC

What is a Post Frame Building? It is essentially a structural framing system used in a wide variety of building applications. More people every day are becoming aware of the economic and environmentally sustainable advantages of Post Frame construction. To address the need for a clear definition of the Post Frame Building system, the following definition was recently approved by the National Frame Building Association (NFBA) Technical & Research committee under the guidance of Dr. Harvey Manbeck:

"Post-Frame Building System. A post-frame building system is characterized by primary structural frames of posts as columns and trusses or rafters as roof framing. The roof framing is attached to the posts, either directly or indirectly through structural headers. Posts are typically graded lumber, graded timbers, laminated lumber or fabricated of composite or hybrid material. Posts are embedded in the soil and supported on isolated footings, or are attached to the top of piers, concrete or masonry walls, slabs-on-grade, or other suitable foundations. Secondary framing members, purlins in the roof and girts in the walls, are attached to the primary framing members to provide lateral support and to transfer sheathing loads, both in-plane and out-of-plane, to the posts and roof framing. Structures are sheathed with a wide variety of materials, including metal and wood structural panels or other suitable materials."

Post Frame buildings are cost effective and enviornmentally sustainable because they use a large amount of renewable structural material and use all materials very efficiently compared to alternative framing systems. Post Frame buildings can be finished with the same interior and exterior finishes of any other framing system or, for ultimate cost savings, they can be covered with light gauge steel panels (similar to pre-engineered steel buildings) which serve as both exterior finish and structural element (replaces the OSB and lap siding with just one material). The material efficiency of Post Frame construction does require a higher degree of certainty in the engineering than other types of construction having more built-in redundancy.

Halberg Engineering is an independent structural engineering consultant specializing in the engineering of Post Frame buildings in a wide variety of applications: commercial, residential, and agricultural. If you have any questions or engineering needs for Post-Frame construction give us a call at 866-694-8602 and ask for Aaron.

Plan Review of Lighting for Commercial Buildings in Wisconsin

reposted here from Safety & Buildings website:
Wisconsin Safety and Buildings Announcement
January 29, 2009

Subject: Reemphasis on commercial buildings general lighting plans and about submittal of emergency lighting plans.

General lighting and emergency lighting will receive more emphasis during commercial buildings plan reviews by Safety and Buildings Division staff effective March 2, 2009. The Wisconsin Commercial Building Code has included requirements for illumination and electrical energy efficiency since 1980.
S&B has been flexible over time about requesting submittal and approval of lighting design plans and calculations. At times division staff have asked for more lighting information than at other times. Whether submitted for review or not, lighting code compliance has been necessary. S&B will renew review of general lighting plans because of concerns that compliance with recent energy efficiency code changes has not been demonstrated.
In March of 2008, substantial emergency lighting and lighting energy efficiency changes occurred; some of the energy efficiency factors have become 30 - 40 percent more stringent. With our nation's and state's focus on building lifetime energy usage, the building lighting designs need to be clearly recognized as consequential.The specific aspect of plan review of emergency lighting plans, important to the safety of occupants and first responders, comes from field observations that some emergency lighting installations are not meeting code requirements. The fact that emergency lighting is often installed late in construction, even after partial occupancy of a building, may have led to less-than-necessary coordination of egress paths and emergency lighting design and installation.
Beginning March 2, 2009, submittal of general lighting plans and emergency lighting plans will be required by the Safety and Buildings Division for plan reviews for: - New buildings; - Additions to buildings;- Initial tenant build-outs within buildings for which initial plans were received on or after March 2.
For plans received on or after March 2, 2009, if S&B commercial building plan reviewers find general lighting and emergency lighting plans have not been submitted for review with the initial building plan review, the reviewers will contact the designer with the option of the designer providing lighting plans as part of the immediate review. If the designer chooses to not do so, the general lighting plan and emergency lighting plan can be submitted later, before installation, for separate plan review.
Fees for the plan reviews are not increased:- For general lighting or emergency lighting plans submitted with building or HVAC plans, there will be no additional fee. (Overall fee calculated per code, Comm 2.31.)
For lighting plans submitted separate from building or HVAC plans, the fee will be the current $75 revision plus the $100 submittal fee, a total of $175. (Per Comm 2.31(1)(f).)
For submittal of plans after construction, the standard late submittal fee of $250 will be assessed, as well as the $100 submittal fee, for a total of $350. (Per Comm 2.31(1)(d)6.)
See the S&B WebSite for general lighting and emergency lighting code and submittal information.

Environmentally Friendly Materials and Practices

A great definition of sustainable construction was presented by Professor David Bohnhoff at this year's Wisconsin Frame Builders Association conference during his discussion of "green" practices:
"Sustainable Construction meets present needs without compromising the ability of future generations to meet their own needs."

Prof. Bohnhoff also pointed out that, in almost every measure, when you look at the factors that go into making a building the most affordable it can be, you are also making the building the most environmentally friendly that it can be. This is a direct result of the fact that much of the cost that goes into a project reflects the recouping the costs of the embodied energy, or the energy required to produce, use, and dispose of the building at the end of its life. The less energy required, the lower the impact on the environment, and less energy also translates to lower cost. Post frame construction is a Win-Win-Win in this regard.

In another point of the discussion, minimizing the life cycle energy costs to condition our occupied spaces leads us to make our spaces as energy efficient as possible to start using less energy per unit of occupied space as soon as possible. This is basically a reason to perform construction sooner than later at any time as improvement in energy efficiency serves as a positive return on investment with constant energy costs, but that return rate would improve in a scenario of increasing energy prices.

So, if you're going to build a structure that uses less energy to condition, you should also look at minimizing the total material usage (embodied energy) that goes into the building. Some types of structures are not particularly efficient, including Timber-frame construction and even full log construction if the logs are harvested, debarked and shpaed on a site away from the buildnig site. The amount of material used can be minimized in our building shapes by looking at regular shaped buildings with good aspect ratios (length to width), not too square (inefficient for natural lighting and structural framing) yet not too narrow (inefficient for energy loss because of high exterior wall area per unit of floor area).

Post Frame construction is just one of many options for energy efficient and environmentally friendly construction although it is obvious that wood material is a replenishable resource (trees, switchgrass, corn: all are "biomass"). But even concrete can be made in more environmentally friendly today when the heat used to produce the concrete is recovered waste heat from other emission systems. This drastically lowers the embodied energy in concrete.

Professor Bohnhoff made some great points about why we should be very wary of mandated green building standards as we've seen over and over again that standards tend to stifle creativity and innovation, which is really what leads us to improvements in all areas of our society. The man-made impact on Global warming should be held in suspicion as many of the promoters of that theory are using more fear and less facts which seems to move towards mandated standards to combat such a large problem, regardless of the cost of implementing those standards.

In so many ways, there are reasons to be optimistic about the future of the built environment as the quality of materials improve, innovative use of energy continues, and intelligent choice of building design continues to get better.
